| Working principle: | Impeller |
| Pump body material: | Cast iron |
| Max. medium temperature: | 50℃ |
| Flow rate: | 0 - 10m3/h |
| Max. Head: | 14m |
| Caliber: | 1"(25mm) |
| Motor power: | 120W - 150W |
| Motor specification: | DC 12V or 24V or 48V |
| Main application | Water, Swimming pool, Garden |
| Model | RD-DC12 | RD-DC24 | RD-DC48 |
| Voltage | DC12V | DC24V | DC48V |
| Power | 120W(0.16HP) | 120W(0.16HP) | 150W(0.20HP) |
| Caliber | 25mm( 1") | 25mm( 1") | 25mm( 1") |
| Capacity |
6m3/h (26.4US.GPM) |
8m3/h (35.2US.GPM) |
10m3/h (44.0US.GPM) |
| Max. head | 7m(23ft) | 12m(39.4ft) | 14m(45.9ft) |
| Casing parts material | Cast iron | ||
| Temperature | 50℃(104℉) | ||
| Main applications | Water | ||
