| Working principle: | Diaphragm |
| Pump body material: | Nylon, glass fiber reinforce |
| Max. medium temperature: | 60℃ |
| Suction: | 5m |
| Flow rate: | 1 - 16L/min |
| Discharge Pressure: | 0 - 150psi (1.0Mpa) |
| Caliber: | 3/8"(10mm) |
| Pressure switch: | With or without |
| Motor power: | 10 - 65W |
| Motor specification: | DC brush, DC brushless, AC220V |
| Main application | Water, RO system, Cleaniing, Spray, etc |
| Model |
Voltage (V) |
Current (A) |
Max Capacity |
Speed (r/min) |
Max Pressure | Suction | Pressure switch | Power | |||||
| (L/min) | (US.GPM) | (psi) | (Bar) | (m) | (ft) | (psi) | (Bar) | (W) | (HP) | ||||
| DP-35 | 24 | 4.8 | 12 | 3.17 | 1300 | 35 | 2.4 | 5 | 16.4 | 35 | 2.4 | 40 | 0.054 |
| 12 | 7 | 9.5 | 2.51 | 1200 | 35 | 2.4 | 5 | 16.4 | 35 | 2.4 | 40 | 0.054 | |
| DP-50 | 24 | 6.0 | 16 | 4.2 | 1800 | 50 | 3.5 | 5 | 16.4 | 50 | 3.5 | 65 | 0.087 |
| DP-60 | 24 | 3 | 5.0 | 1.32 | 1200 | 60 | 4.1 | 5 | 16.4 | 60 | 4.1 | 40 | 0.054 |
| 12 | 6 | 5.0 | 1.32 | 1200 | 60 | 4.1 | 5 | 16.4 | 60 | 4.1 | 40 | 0.054 | |
| DP-60A | 12 | 3.5 | 3.0 | 0.79 | 375 | 60 | 4.1 | 5 | 16.4 | - | - | 20 | 0.027 |
| DP-100 | 24 | 1.1 | 1.2 | 0.32 | 375 | 100 | 6.9 | 5 | 16.4 | 100 | 6.9 | 10 | 0.013 |
| DP-100A | 24 | 1.1 | 1.2 | 0.32 | 375 | 100 | 6.9 | 5 | 16.4 | - | - | 10 | 0.013 |
| DP-125 | 24 | 1.0 | 1.0 | 0.26 | 375 | 125 | 8.6 | 5 | 16.4 | 125 | 8.6 | 10 | 0.013 |
| DP-130 | 24 | 1.2 | 1.7 | 0.45 | 470 | 130 | 9.0 | 5 | 16.4 | - | - | 15 | 0.020 |
| 12 | 2.2 | 1.7 | 0.45 | 470 | 130 | 9.0 | 5 | 16.4 | - | - | 15 | 0.020 | |
| DP-130B | 12 | 2.2 | 1.7 | 0.45 | 470 | 130 | 9.0 | 5 | 16.4 | 125 | 9.0 | 15 | 0.020 |
| DP-150 | 24 | 4.0 | 5.3 | 1.4 | 1200 | 150 | 10 | 5 | 16.4 | - | - | 40 | 0.054 |
| 12 | 6.5 | 5.3 | 1.4 | 1200 | 150 | 10 | 5 | 16.4 | - | - | 40 | 0.054 | |
